Action Yes No
Step 5
Replace the sensor. See
“Sensor (booklet maker aligner home) removal”
on page 495.
Does the problem remain?
Go to step 6. The problem is solved.
Step 6
a Test the motor (booklet maker aligner).
Enter the Diagnostics menu, and then navigate to:
Motor Tests > Booklet Maker Motor Test > Stopper
b Check if the aligner is moving properly.
Is it moving properly?
Go to step 8. Go to step 7.
Step 7
a Remove the right cover.
b Reseat the cable on the motor.
c Make sure that the motor is properly installed.
d Check the motor and cable for damage, and replace if necessary. See
“Motor (booklet maker aligner) removal” on page 491.
Does the problem remain?
Go to step 8. The problem is solved.
Step 8
a Remove the booklet maker aligner assembly.
b Make sure that the parts are properly installed.
c Check the parts for wear or damage, and replace if necessary. See
“Booklet maker—Aligner assembly” on page 621.
Does the problem remain?
Go to step 9. The problem is solved.
Step 9
a Reseat the cable J10 on the booklet maker controller board.
b If applicable, reseat the junction connectors on the cable.
c Make sure that the cable does not block the path of moving parts.
d Check the cable for damage, and replace if necessary.
Does the problem remain?
Go to step 10. The problem is solved.
Step 10
a Reseat the interface cable on the booklet maker controller board and
SHPF controller board.
b Reseat the junction connector on the cable.
c Check the cable for damage, and replace if necessary.
Does the problem remain?
Go to step 11. The problem is solved.
4021, 7421
Diagnostic information
134
