Lexmark MS911 - SHPF Rear Cover Removal; SHPF Top Door Removal

SHPF rear cover removal
1 Remove the eight screws.
2 Remove the cover.
SHPF top door removal
1 Remove the front door. See “SHPF front door removal” on page 336.
2 Remove the top inner cover. See “SHPF top inner cover removal” on page 336.
4021, 7421
Repair information
339
