Lexmark MS911 - SHPF Diverter Feed Roller Knob Removal

3 Unlatch and then remove the knob (B).
4 Remove the cover.
SHPF diverter feed roller knob removal
1 Remove the front door. See “SHPF front door removal” on page 336.
2 Remove the top inner cover. See “SHPF top inner cover removal” on page 336.
4021, 7421
Repair information
337
