Symptoms
Staple finisher symptoms
Staple finisher symptoms
Symptom Action
A persistent Close door G message appears.
See
“Staple finisher locks service check” on
page 157.
A persistent Remove paper from standard
output bin message appears.
See
“Staple finisher bin stack height assembly
failure service check” on page 158.
The paper are not stapled. See
“Staple finisher stapling failure service check”
on page 161.
Staple finisher locks service check
Action Yes No
Step 1
a Make sure that the staple finisher is properly installed.
b Reseat the interface cable that is plugged into the printer.
c Reset the printer.
Does the problem remain?
Go to step 2. The problem is solved.
Step 2
a Make sure that the lock switch is properly installed.
b Reseat the cable on the switch.
c Check the switch for damage, and replace if necessary. See “Staple
finisher lock switch removal” on page 241.
Does the problem remain?
Go to step 3. The problem is solved.
Step 3
a Reseat the cable CN106 on the staple finisher controller board.
b If applicable, reseat the junction connectors on the cable.
c Make sure that the cable does not block the path of moving parts.
d Check the cable for damage, and replace if necessary.
Does the problem remain?
Go to step 4. The problem is solved.
4021, 7421
Diagnostic information
157
