Installation notes:
a Install the spring, and then install the pin.
b Install the gears with the teeth (A) facing each other.
Sensor (SHPF top bin full) removal
1 Remove the rear cover. See “SHPF rear cover removal” on page 339.
2 Remove the elevator motor bracket. See “Motor (SHPF elevator) removal” on page 359.
3 Remove the screw (A).
4 Remove the sensor, and then disconnect the cable.
4021, 7421
Repair information
363
