4 Remove the clip (B), and then remove the gear.
Sensor (booklet maker decurl) removal
1 Remove the front cover. See “Booklet maker front cover removal” on page 456.
2 Remove the transport and decurl motor bracket removal. See “Transport and decurl motor bracket removal” on
page 479.
3 Disconnect the cable (A), and then remove the sensor.
