Lexmark MS911 - Booklet Maker Front Cover Removal; Booklet Maker Lower Paddle Removal

Booklet maker lower paddle removal
1 Remove the aligner jam access cover. See “Booklet maker aligner jam access door removal” on page 460.
2 Remove the four paddles (A).
Booklet maker front cover removal
1 Remove the screw (A), and then remove the knob.
2 Remove the four screws (B), and then remove the cover.
4021, 7421
Repair information
456
