c Tighten the top screw (C), and then tighten the bottom screw (D).
Motor (staple finisher elevator) removal
1 Remove the rear cover. See “Staple finisher rear cover removal” on page 230.
2 Disconnect the three cables (A).
3 Remove the two screws (B), and then remove the cable holder.
4021, 7421
Repair information
250
