Staple finisher exit guide removal
1 Remove the front cover. See “Staple finisher front cover removal” on page 229.
2 Remove the rear cover. See “Staple finisher rear cover removal” on page 230.
3 Remove the top cover. See “Staple finisher top cover removal” on page 231.
4 Remove the guide.
Installation note: Position the static brushes outside the guide.
Staple finisher bin removal
1 Remove the seven screws (A).
2 Remove the bin.
4021, 7421
Repair information
232
