4 Remove the elevator drive gears. See “Staple finisher elevator drive gears removal” on page 271.
5 Remove the elevator belts. See “Staple finisher elevator belts removal” on page 272.
6 Remove the gear (A).
7 Remove the screw (B), and then remove the gear bracket.
8 Remove the two screws (C), and then remove the gear bracket.
4021, 7421
Repair information
275
