Assembly 10: Staple finisher—Exit section 1
Asm-index P/N Units/opt Units/FRU Description Removal procedure
1 40X9548 2 1 Staple finisher upper exit
roller holder
“Staple finisher upper exit roller belts and
gear removal” on page 309
2 40X9356 1 1 Staple finisher eject cam
“Staple finisher eject cam removal” on
page 307
3 40X9357 1 1 Staple finisher upper exit
actuator
“Staple finisher upper exit actuator removal”
on page 285
4 40X9360 1 1 Staple finisher upper exit
roller primary belt
“Staple finisher upper exit roller belts and
gear removal” on page 309
5 40X9291 2 1 Staple finisher upper exit
roller
“Staple finisher upper exit roller removal” on
page 308
6 40X9813 1 1 Staple finisher upper exit
roller secondary belt
“Staple finisher upper exit roller belts and
gear removal” on page 309
7 40X9820 1 1 Staple finisher upper exit
roller secondary gear
“Staple finisher upper exit roller removal” on
page 308
8 40X9904 1 1 Staple finisher upper exit
roller primary gear
“Staple finisher upper exit roller belts and
gear removal” on page 309
9 40X9814 2 1 Staple finisher eject guide
“Staple finisher eject guide removal” on
page 306
4021, 7421
Parts catalog
556
