Lexmark MS911 - Page 558

Assembly 11: Staple finisher—Exit section 2
Asm-index P/N Units/opt Units/FRU Description Removal procedure
1 40X9374 1 1 Staple finisher exit section
cable
--
2 40X9343 1 1 Sensor (staple finisher upper
exit roller)
“Sensor (staple finisher upper exit roller)
removal” on page 256
3 40X9366 1 1 Motor (staple finisher exit)
“Motor (staple finisher exit) removal” on
page 253
4 40X9366 1 1 Motor (staple finisher upper
exit)
“Motor (staple finisher upper exit) removal”
on page 251
5 40X9820 1 1 Staple finisher upper exit
roller drive gear
“Staple finisher upper exit roller drive gears
removal” on page 280
6 40X9822 1 1 Staple finisher upper exit
roller drive belt
--
7 40X9369 1 1 Staple finisher exit roller
drive belt
--
8 40X9821 1 1 Staple finisher exit roller
drive gear
“Staple finisher exit roller drive belts and
gears removal” on page 283
9 40X9824 1 1 Staple finisher exit guide lift
cam gear
“Staple finisher exit guide lift cam removal”
on page 279
10 40X9377 4 1 Staple finisher exit guide lift
cam
“Staple finisher exit guide lift cam removal”
on page 279
11 40X9376 2 1 Staple finisher upper exit belt
“Staple finisher exit roller drive belts and
gears removal” on page 283
12 40X9819 1 1 Staple finisher upper exit
gear
“Staple finisher exit roller drive belts and
gears removal” on page 283
13 40X9818 1 1 Staple finisher upper exit
idler gear
“Staple finisher exit roller drive belts and
gears removal” on page 283
14 40X9375 1 1 Staple finisher exit gear
“Staple finisher exit roller drive belts and
gears removal” on page 283
15 40X9376 2 1 Staple finisher exit belt
“Staple finisher exit roller drive belts and
gears removal” on page 283
4021, 7421
Parts catalog
558
