Assembly 13: Staple finisher—Bin section 1
Asm-index P/N Units/opt Units/FRU Description Removal procedure
1 40X9346 1 1 Staple finisher exit guide
“Staple finisher exit guide removal” on
page 232
2 40X9340 1 1 Staple finisher bin
“Staple finisher bin removal” on page 232
3 40X9345 4 1 Staple finisher elevator wheel --
4 40X9903 1 1 Staple finisher elevator top
front gear
“Staple finisher elevator drive gears
removal” on page 271
5 40X9343 1 1 Sensor (staple finisher elevator
home)
“Sensor (staple finisher elevator home)
removal” on page 257
6 40X9341 2 1 Staple finisher elevator belt
“Staple finisher elevator belts removal” on
page 272
7 40X9812 2 1 Staple finisher elevator bottom
gear
“Staple finisher elevator drive gears
removal” on page 271
8 40X9909 2 1 Staple finisher belt holder
“Staple finisher elevator belts removal” on
page 272
9 40X9640 1 1 Staple finisher bin extender 1 --
10 40X9645 1 1 Staple finisher bin extender 2 --
11 40X9342 1 1 Staple finisher elevator top
rear gear
“Staple finisher elevator drive gears
removal” on page 271
4021, 7421
Parts catalog
562
