Assembly 23: SHPF—Transport section 2
Asm-index P/N Units/opt Units/FRU Description Removal procedure
1 40X9565 1 1 SHPF top bin transport roller belt --
2 40X9573 1 1 SHPF top bin transport roller gear --
3 40X9574 1 1 SHPF diverter feed roller gear
“SHPF entrance and diverter feed roller
gears removal” on page 393
4 40X9566 1 1 SHPF diverter feed roller belt --
5 40X9570 1 1 SHPF top bin exit sensor cable --
6 40X8869 1 1 Sensor (SHPF top bin exit)
“Sensor (SHPF top bin exit) removal” on
page 397
7 40X9400 1 1 SHPF top bin exit sensor cover
“Sensor (SHPF top bin exit) removal” on
page 397
8 40X9571 1 1 SHPF top bin exit sensor actuator
“Sensor (SHPF top bin exit) removal” on
page 397
9 40X9426 1 1 SHPF top bin exit paper guide
“SHPF top bin exit paper guide removal”
on page 398
10 40X9574 1 1 SHPF diverter feed roller gear --
11 40X9221 1 1 SHPF entrance roller belt
“SHPF entrance and diverter feed roller
gears removal” on page 393
12 40X9224 1 1 SHPF diverter cam drive gear
“SHPF entrance and diverter feed roller
gears removal” on page 393
13 40X8869 1 1 Sensor (SHPF diverter cam)
“Sensor (SHPF diverter cam) removal”
on page 392
14 40X9399 2 1 SHPF jam removal knob
“SHPF diverter feed roller knob
removal” on page 337
15 40X9558 1 1 SHPF diverter cam belt
“SHPF diverter cam removal” on
page 391
16 40X9270 1 1 SHPF diverter cam gear
“SHPF diverter cam removal” on
page 391
17 40X8943 1 1 SHPF diverter cam sensor encoder
“SHPF diverter cam removal” on
page 391
18 40X9569 1 1 SHPF compiler feed roller belt --
19 40X9572 1 1 SHPF compiler feed roller gear --
20 40X9568 1 1 SHPF booklet maker pre-feed
roller belt
--
21 40X9572 1 1 SHPF top bin exit roller gear --
22 40X9574 1 1 SHPF booklet maker pre-feed
roller gear
--
23 40X9567 1 1 SHPF top bin exit belt --
4021, 7421
Parts catalog
582
