Assembly 24: SHPF—Transport section 3
Asm-index P/N Units/opt Units/FRU Description Removal procedure
1 40X9582 1 1 SHPF diverter feed roller
“SHPF diverter feed roller removal” on
page 426
2 40X9577 1 1 SHPF booklet maker feed
guide
--
3 40X8968 1 1 Sensor (SHPF booklet gate)
“SHPF booklet maker upper pre‑feed guide
removal” on page 423
4 40X9440 2 1 Ball bearing --
5 40X9589 6 1 Ball bearing --
6 40X9587 1 1 SHPF diverter cam
“SHPF diverter cam removal” on page 391
7 40X9580 1 1 SHPF jam access door
“SHPF jam access door removal” on page
342
8 40X9586 1 1 SHPF top bin transport roller
“SHPF top bin transport roller removal” on
page 438
9 40X9585 1 1 SHPF top bin exit roller
“SHPF top bin exit roller removal” on
page 434
10 40X9584 1 1 SHPF booklet maker pre-feed
roller
“SHPF booklet maker pre-feed roller
removal” on page 421
11 40X9578 1 1 SHPF booklet maker lower
pre-feed guide
“SHPF booklet maker lower pre-feed guide
removal” on page 422
12 40X9490 1 1 SHPF booklet maker movable
guide
“SHPF booklet maker upper pre‑feed guide
removal” on page 423
13 40X8883 1 1 SHPF booklet maker upper
pre-feed guide
“SHPF booklet maker upper pre‑feed guide
removal” on page 423
14 40X9579 1 1 SHPF booklet gate sensor
cable
“SHPF booklet maker upper pre‑feed guide
removal” on page 423
15 40X9353 4 1 SHPF booklet maker pre-feed
idler roller
“SHPF entrance roller removal” on page
447
4021, 7421
