Lexmark MS911 - Page 590

Assembly 26: SHPF—Elevator bin section 1
Asm-index P/N Units/opt Units/FRU Description Removal procedure
1 40X8954 2 1 SHPF elevator bin stack height
sensor actuator arm
“SHPF elevator bin stack height sensor
actuator arms and gears removal” on
page 351
2 40X9521 1 1 Booklet maker rail --
3 40X8881 2 1 Booklet maker mount --
4 40X8869 1 1 Sensor (SHPF elevator bin stack
height actuator arm control)
“SHPF upper left cover sensors removal”
on page 349
5 40X9043 1 1 SHPF elevator bin front stack
height sensor actuator
“SHPF elevator bin stack height sensor
actuator removal” on page 350
6 40X9597 1 1 SHPF elevator bin stack height
cable
--
7 40X9538 1 1 Sensor (SHPF elevator bin stack
height, receive)
“SHPF upper left cover sensors removal”
on page 349
8 40X8869 1 1 Sensor (SHPF elevator bin front
stack height)
“SHPF upper left cover sensors removal”
on page 349
9 40X8869 1 1 Sensor (SHPF elevator bin rear
stack height)
“SHPF upper left cover sensors removal”
on page 349
10 40X9540 1 1 Sensor (SHPF elevator bin stack
height, transmit)
“SHPF upper left cover sensors removal”
on page 349
11 40X9477 1 1 SHPF elevator bin rear stack
height sensor actuator
“SHPF elevator bin stack height sensor
actuator removal” on page 350
12 40X9498 4 1 SHPF elevator bin stack height
finger holder
--
13 40X9021 4 1 SHPF elevator bin stack height
finger
“SHPF elevator bin stack height sensor
actuator removal” on page 350
14 40X9532 1 1 Motor (SHPF elevator bin stack
height)
“Motor (SHPF elevator bin stack height)
removal” on page 353
15 40X9596 1 1 SHPF elevator bin stack height
drive gear
“SHPF elevator bin stack height drive gear
removal” on page 352
16 40X9594 1 1 SHPF elevator bin stack height
sensor actuator arm gear
“SHPF elevator bin stack height sensor
actuator arms and gears removal” on
page 351
17 40X8869 1 1 Sensor (SHPF elevator bin full)
“Sensor (SHPF elevator bin full) removal”
on page 343
18 40X9506 1 1 SHPF elevator bin full sensor
actuator
“Sensor (SHPF elevator bin full) removal”
on page 343
19 40X9488 1 1 SHPF lower left cover
“Lower left cover removals” on page 344
20 40X9877 1 1 SHPF elevator bin full sensor
cable
“Sensor (SHPF elevator bin full) removal”
on page 343
4021, 7421
Parts catalog
590
