Assembly 27: SHPF—Elevator bin section 2
Asm-index P/N Units/opt Units/FRU Description Removal procedure
1 40X9440 2 1 Ball bearing --
2 40X9603 2 2 SHPF elevator belt
“SHPF elevator belts removals” on
page 377
3 40X9607 4 3 SHPF elevator gear --
4 40X9311 2 4 SHPF elevator gear bracket --
5 40X9427 2 5 SHPF elevator belt spring
“SHPF elevator belts removals” on
page 377
6 40X9605 1 6 SHPF elevator bin front bracket
“SHPF elevator belts removals” on
page 377
7 40X8991 2 7 SHPF elevator belt holder
“SHPF elevator belts removals” on
page 377
8 40X9609 1 8 SHPF elevator bin
“SHPF elevator bin removal” on page 331
9 40X9517 1 9 SHPF elevator bin extender
“SHPF elevator bin removal” on page 331
10 40X9168 1 10 SHPF elevator motor encoder --
11 40X9601 1 11 SHPF elevator motor encoder
belt
--
12 40X9849 1 12 SHPF elevator bin clutch gear
“SHPF elevator drive assembly removal”
on page 362
13 40X9631 1 13 SHPF elevator bin clutch
bushing
“SHPF elevator drive assembly removal”
on page 362
14 40X9604 1 14 SHPF elevator bin rear bracket
“SHPF elevator belts removals” on
page 377
15 40X9636 1 15 SHPF elevator drive gear
“SHPF elevator drive assembly removal”
on page 362
16 40X9187 1 16 SHPF elevator bin idler gear
“SHPF elevator drive assembly removal”
on page 362
17 40X8869 1 17 Sensor (SHPF elevator
position)
“Sensor (SHPF elevator position) removal”
on page 361
18 40X9534 1 18 Motor (SHPF elevator)
“Motor (SHPF elevator) removal” on
page 359
4021, 7421
Parts catalog
592
