Assembly 37: Booklet maker—Fold section 2
Asm-index P/N Units/opt Units/FRU Description Removal procedure
1 40X9442 1 1 Trifold knife actuator
“Bifold upper roller removal” on page 506
2 40X9449 2 1 Bifold rollers
“Bifold upper roller removal” on page 506
“Bifold lower roller removal” on page 509
3 40X9414 1 1 Bifold guide --
4 40X9861 1 1 Bifold roller timing gear
“Bifold upper roller removal” on page 506
5 40X9439 2 1 Bifold roller springs
“Bifold roller springs removal” on page 480
6 40X9862 1 1 Bifold guide home sensor
actuator
“Bifold roller drive gears removal” on
page 522
7 40X9863 1 1 Bifold guide drive gear
“Bifold guide drive gears removal” on
page 525
8 40X9447 1 1 Motor (bifold guide)
“Bifold guide drive gears removal” on
page 525
9 40X8869 1 1 Sensor (bifold guide home)
“Sensor (bifold guide home) removal” on
page 488
10 40X9446 1 1 Motor (trifold guide)
“Motor (trifold guide) removal” on page 489
11 40X8869 1 1 Sensor (trifold guide home)
“Sensor (trifold guide home) removal” on
page 490
12 40X9440 4 1 Bifold roller ball bearing
“Bifold upper roller removal” on page 506
13 40X9443 1 1 Lower bifold roller gear
“Bifold lower roller removal” on page 509
14 40X9444 1 1 Trifold knife front idler gear
“Bifold roller drive gears removal” on
page 522
15 40X9352 1 1 Trifold exit roller --
16 40X9441 1 1 Trifold knife rear idler gear
2
“Bifold roller drive gears removal” on
page 522
17 40X9859 2 1 Bifold roller gear
“Bifold roller drive gears removal” on
page 522
18 40X9860 2 1 Trifold knife rear idler gear
1
“Bifold roller drive gears removal” on
page 522
4021, 7421
