Lexmark MS911 - Page 614

Assembly 38: Booklet maker—Fold section 3
Asm-index P/N Units/opt Units/FRU Description Removal procedure
1 40X9562 2 1 Trifold knife slider --
2 40X9459 2 1 Trifold knife springs
“Trifold knife springs removal” on page 505
3 40X9458 1 1 Trifold gate actuator
“Trifold gate actuator removal” on page
490
4 40X9454 1 1 Trifold jam knob
“Trifold jam knob removal” on page 455
5 40X9865 1 1 Bifold exit roller gear
“Trifold gears removal” on page 473
6 40X9453 1 1 Trifold roller gear
“Trifold gears removal” on page 473
7 40X9428 2 1 Booklet maker exit roller
springs
“Booklet maker exit roller springs removal”
on page 455
8 40X9864 1 1 Bifold exit roller
“Trifold rollers removal” on page 472
9 40X9452 1 1 Trifold roller
“Trifold rollers removal” on page 472
10 40X9219 1 1 Booklet maker fold exit
sensor cable
--
11 40X8968 1 1 Sensor (booklet maker fold
exit)
“Sensor (booklet maker fold exit) removal”
on page 515
12 40X9524 1 1 Trifold diverter
“Trifold diverter removal” on page 514
13 40X9457 1 1 Bifold jam access door hinge
“Trifold knife removal” on page 505
4021, 7421
Parts catalog
614
