Assembly 39: Booklet maker—Transport section
Asm-index P/N Units/opt Units/FRU Description Removal procedure
1 40X9353 4 1 Booklet maker transport idler
roller
“Booklet maker transport idler rollers
removal” on page 467
2 40X8869 2 1 Sensor (booklet maker
transport)
“Sensor (booklet maker transport)
removal” on page 467
3 40X9463 1 1 Booklet maker transport
sensor actuator
“Sensor (booklet maker transport)
removal” on page 467
4 40X9600 1 1 Booklet maker decurl lever
“Booklet maker decurl lever removal” on
page 468
5 40X9461 1 1 Booklet maker transport
roller
“Booklet maker transport roller removal”
on page 482
6 40X9867 1 1 Booklet maker transport
section extension cable
--
7 40X9469 1 1 Booklet maker transport gear
“Booklet maker transport gear and belt
removal” on page 481
8 40X9467 1 1 Booklet maker transport belt
“Booklet maker transport gear and belt
removal” on page 481
9 40X8869 1 1 Sensor (booklet maker decurl)
“Sensor (booklet maker decurl) removal” on
page 484
10 40X9474 1 1 Booklet maker transport
section cable
--
11 40X9470 1 1 Motor (booklet maker
transport)
“Motor (booklet maker transport) removal”
on page 478
12 40X9446 1 1 Motor (booklet maker decurl)
“Motor (booklet maker decurl) removal” on
page 479
13 40X9468 1 1 Booklet maker decurl gears
“Booklet maker decurl gears removal” on
page 483
14 40X9866 1 1 Booklet maker decurl gears
“Booklet maker decurl gears removal” on
page 483
15 40X9438 1 1 Booklet maker jam access
door
“Booklet maker jam access door removal”
on page 465
16 40X9473 1 1 Booklet maker decurl guide
“Booklet maker decurl guide removal” on
page 485
17 40X9868 1 1 Transport and compiler
section cable
--
18 40X9296 1 1 Booklet maker transport
paper guide lever
“Booklet maker transport paper guide lever
removal” on page 469
19 40X9869 1 1 Booklet maker transport
sensor cable
--
