Assembly 43: Booklet maker—Exit section
Asm-index P/N Units/opt Units/FRU Description Removal procedure
1 40X9501 1 1 HPBF bin bail
“HPBF bin bail removal” on page 333
2 40X9502 1 1 HPBF exit roller cover
“HPBF exit roller cover removal” on
page 347
3 40X9503 1 1 HPBF exit roller cover spring
“HPBF exit roller cover removal” on
page 347
4 40X9538 1 1 Sensor (HPBF bin empty,
transmit)
“HPBF lower left cover sensors removals”
on page 347
5 40X9508 1 1 HPBF lower left cover
“Lower left cover removals” on page 344
6 40X9499 1 1 HPBF bin
“Lower left cover removals” on page 344
7 40X9540 1 1 Sensor (HPBF bin empty,
receive)
“HPBF lower left cover sensors removals”
on page 347
8 40X9504 1 1 HPBF bin empty sensor cable --
9 40X8869 1 1 Sensor (SHPF elevator bin full)
“HPBF lower left cover sensors removals”
on page 347
10 40X9506 1 1 HPBF elevator bin full sensor
actuator
“HPBF lower left cover sensors removals”
on page 347
11 40X9877 1 1 HPBF elevator bin full sensor
cable
--
4021, 7421
