Routing elements
125
System functions and features as of R4.1
syd-0570/1.2 – R4.1 – 08.2016
Alternative Destination is Busy
If the original destination is busy, the call is routed to the call distribution element en-
tered under CDE if busy If the alternative destination is also busy, the call is routed
to the next alternative destination -- if such a destination has been configured. This
process can be repeated up to the fifth call distribution element. If the destination of the
fifth call distribution element is also busy, the caller will obtain the busy tone.
Fig. 60 Routing to an alternative destination if the original destination is busy
Note:
It makes no sense to use the destination combinations User+UG, busy and User+KT, busy
together with CDE if busy.
->
->
->
220
230
220
230
User
CDE if no answer: 3
User
Call distribution element 3
Call distribution element 2
Busy
