Call routing
253
System functions and features as of R4.1
syd-0570/1.2 – R4.1 – 08.2016
– All calls sent to the public network via Zurich are routed via a separate route. Its
configuration must
Numbering plan identifier (NPI) = E.164 must be set so that PINX2 recognises a
call as external and routes it accordingly.
– All calls addressed to PINX2 users in Zurich are routed via another route whose
configuration contains the setting Numbering plan identifier (NPI) = PNP.
– Both routes can be allocated to the same trunk group.
• Trunk group settings:
– Network type = Private
– Protocol = PSS1
– Create CLIP number automatically = Activated
Tab. 72 Settings for break-out routing at the source PINX
(PINX 1 in Geneva)
Parameter Parameter value
User configuration:
• Create CLIP number automatically Deactivated (permanently CLIP number entry is used)
• Numbering plan identifier (NPI) E.164
• Type of number (TON) National
• CLIP number 022 827 9x xx
(x stands for the user’s DD number)
LCR table:
• ... ...
• 01 810 Zurich (allocate to the "Zurich" routing table)
• 01 811 Zurich (allocate to the "Zurich" routing table)
• 01 813 Zurich (allocate to the "Zurich" routing table)
• ... ...
"Zurich" routing table:
• Time zone x•Network provider: BreakOutZH
• Times: Allocate the times for "BreakOutZH"
Network operator table:
• Network provider "BreakOutZH" Route 5
• Conversion rule N (add dialled phone number)
Route 5:
• Name Zurich, ISDN exchange
• Trunk group 2
• External digit barring Deactivated (do not consult digit barring)
• Max outgoing calls Number of calls going out simultaneously via this route
• Numbering plan identifier (NPI) E.164
• Type of number (TON) Unknown
Trunk group 2:
• Name Zurich, PINX 2
