Call logging (CL)
289
System functions and features as of R4.1
syd-0570/1.2 – R4.1 – 08.2016
Caller identification 1 and caller identification 2
These fields have a different meaning depending on the direction (incoming or outgo-
ing calls).
• Caller identification 1, incoming:
The number which the calling user wants to present to the called user is entered
here. This number is displayed as CLIP on system phones.
• Caller identification 2, incoming:
A call number from the calling user that has been verified by the network provider
and found to be valid is entered here.
Fig. 155 Caller identification incoming
• Caller identification 1, outgoing:
On the OCL report at the gateway/transit PINX: The user call number valid within
the network is entered here.
On the OCL report at the source PINX no number is entered in this field.
• Caller identification 2, outgoing:
On the OCL report at the source/transit PINX: The user call number valid within the
PISN is entered here.
On the OCL report at the gateway PINX: The user’s DDI number is entered here.
On a stand-alone communication server the entries are output analogue to a source
PINX.
0848 80 24 44
PC
PC
032 624 33 00
032 624 33 99
032 624 33 00
PINX 1
PINX 2
Root no.
Caller ID 1: 0848 80 24 44
Caller ID 2: 032 624 33 00
Caller ID 1: 0848 80 24 44
Caller ID 2: 032 624 33 00
Call
Logging
Call
Logging
DDI:54
CLIP on public exchange
Commu-
nication
server
