Call logging (CL)
290
System functions and features as of R4.1
syd-0570/1.2 – R4.1 – 08.2016
Fig. 156 Caller identification outgoing
Destination number 1 and destination number 2
These fields have a different meaning depending on the direction (incoming or outgo-
ing calls).
• Destination number 1, incoming:
– For incoming calls: no entry.
– For calls to the DDI number for integrated external/mobile phone: Enter the in-
struction sequence selected in DTMF mode.
• Destination number 2, incoming:
– For the gateway PINX and the stand-alone communication server: Enter the des-
tination number received from the network provider (e.g. Direct dialling number).
– For the transit and destination PINX: The PISN user number of the called user is
entered here.
032 624 33 00
032 624 33 99
032 624 24 00
032 624 24 99
PC
PC
Call
Logging
Commu-
nication
server
Call
Logging
Region 60
Region 50
PINX 2
PINX 1
DDI:54
User no. 300
Caller ID 1: –
Caller ID 2: 50 300
Caller ID 1: 50 300
Caller ID 2: 53
DDI 53 -> User 50 300
