Item Notes Description
TKIP / AES - TKIP / AES mixed mode. Client stations can associate with this device via TKIP or
AES. Enter a Pre-Shared Key. The length of the key is from 8 to 63 characters.
Save Button Click the Save button to save the current configuration.
Undo Button Click the Undo button to restore configuration to previous setting before saving.
Apply Button Click the Apply button to apply the saved configuration.
Table 67 – WDS Hybrid Mode
3.3.2 Wireless Client List
The Wireless Client List page shows the information of wireless clients which are associated with this device.
Go to Basic Network > WiFi > Wireless Client List Tab.
3.3.2.1 Select Target WiFi
Figure 117 – Target WiFi
Item Notes Description
Operation Band (mandatory
field)
Specify the intended operation band for the WiFi module.
Multiple AP
Names
Mandatory field.
Default setting:
All
Specify the VAP to show the associated clients information in the following Client List. By
default, All VAPs are selected.
Figure 118 – Target WiFi
3.3.2.2 Show Client List
The following Client List shows the information for wireless clients that are associated with the selected VAP(s).
Figure 119 – Client List
Item Description
IP Address Configuration & Address
It shows the Client’s IP address and the method that it was obtained.
Dynamic means the IP address is derived from a DHCP server.
Static means the IP address is a fixed one that is self-filled by the client.
Host Name Displays the host name of the client.
