Item Notes Description
Static Routing Disabled by default. Check the Enable box to activate this function
Table 93 – Enable Static Routing
3.6.1.3 Create / Edit Static Routing Rules
The Static Routing Rule List shows the setup parameters of all static routing rule entries. To configure a static routing rule,
you must specify related parameters including the destination IP address and subnet mask of the dedicated host/server or
subnet, the IP address of a peer gateway, the metric and the rule activation.
Figure 163 – Create / Edit Static Routing Rules
The router allows you to customise your static routing rules. It supports up to a maximum of 64 rule sets. When Add button
is applied, Static Routing Rule Configuration screen will appear, while the Edit button at the end of each static routing rule
can let you modify the rule.
Figure 164 – IPv4 Static Routing Rule Configuration
Item Notes Description
Destination IP Mandatory field. Enter
in IPv4 format.
Specify the Destination IP of this static routing rule.
Subnet Mask 255.255.255.0
Default setting: (/24)
Specify the Subnet Mask of this static routing rule.
Gateway IP Mandatory field. Enter
in IPv4 format.
Specify the Gateway IP of this static routing rule.
Interface Default setting: Auto Select the Interface of this static routing rule. It can be Auto,
or the available WAN / LAN interfaces.
Metric Mandatory field.
Numeric string format.
The Metric of this static routing rule.
Value Range: 0 - 255.
Rule Disabled by default. Click  Enable to activate this rule.
Save Button Click the Save button to save the configuration
Undo Button Click the Undo button to restore what you just configured
back to the previous setting.
