3.6.2.5 Dynamic Routing Setting
Navigate to the Basic Network > Routing > Dynamic Routing tab.
The dynamic routing setting allows user to customize RIP, OSPF, and BGP protocol through the router based on their office
setting.
On the "Dynamic Routing" page, there are seven configuration windows for the dynamic routing feature. They are the "RIP
Configuration" window, "OSPF Configuration" window, "OSPF Area List", "OSPF Area Configuration", "BGP Configuration",
"BGP Neighbor List" and "BGP Neighbor Configuration" window. RIP, OSPF and BGP protocols can be configured individually.
The "RIP Configuration" window lets you choose which version of RIP protocol to be activated or disable it. The "OSPF
Configuration" window lets you activate the OSPF dynamic routing protocol and specify its backbone subnet, while the "OSPF
Area List" window lists all defined areas in the OSPF network. The "BGP Configuration" window allows you to activate the
BGP dynamic routing protocol and specify its self ID. The "BGP Neighbor List" window lists all defined neighbors in the BGP
network.
3.6.2.6 Enable Dynamic Routing
Check the "Enable" box to activate the "Dynamic Routing" feature.
Figure 169 – Dynamic Routing Configuration
Item Notes Description
Dynamic Routing Disabled by default. Check  Enable to activate this function
Table 95 – Dynamic Routing Configuration
3.6.2.7 RIP Configuration
The RIP configuration setting allows you to customise the RIP protocol
.
Figure 170 – RIP Configuration
Item Notes Description
RIP Enable Default setting: Disable Select Disable, RIP v1 or RIP v2.
Table 96 – RIP Configuration
