NetCommWireless NTC-400 Series User Manual

NTC-400 Series
161 of 361
© NetComm Wireless 2018
Item Notes Description
Group to Enter text string.
Optional field.
Enter a group name if you would like to assign the user to
a particular user group.
Profile Mandatory field.
Enabled by default.
Check  Enable to activate the user profile.
Save Button Click the Save button to save the settings
Undo Button Click the Undo button to cancel the settings
Table 112 – User Profile Configuration
4.2.3 User Group
User Groups are composed of several user accounts which share common properties.
The User Group List section shows all user groups and some of their settings.
To view the User Group List section open the Object Definition submenu, select User and then click its User Group tab.
The User Group List contains basic details of all currently defined User Groups:
Figure 197 – User Group List
Item Notes Description
ID Auto-
filled with an
integer.
The user group’s system generated reference number.
Group Name System generated. Name entered in User Group Configuration section, see next.
Click this group’s Edit button in the Actions column to change this
name.
User
Member List
System generated. Multiple users are selected using the Choice button in the User
Group Configuration section, see next.
Click this group’s Edit button in the Actions column to add or remove
user members.
Bound
Services
System generated. To change these settings, click this group’s Edit button in the Actions
column and make the required changes in the User Group
Configuration section, see next.
Enable Checkbox.
Cannot be
changed from this
list.
Check  Enable to activate the user group for use in other
applications throughout the NTC-400 Series Router interface.
When  Enable is unchecked, it is not available for use in other NTC-
400 Series Routersettings.

NetCommWireless NTC-400 Series Specifications

General

Brand	NetCommWireless
Model	NTC-400 Series
Category	Network Router
Language	English
