Item Notes Description
Normal Level Default setting: Low Specify the Normal Level: Low or High
Total Signal Period Mandatory field.
Numeric String format
Specify the Total Signal Period.
Value Range: 10 - 10000 ms.
Repeat & Counter Disabled by default. Click Enable to activate the repeated Digital Output, and
specify the Repeat times.
Value Range: 0 - 65535.
Duty Cycle Mandatory field.
Numeric String format
Specify the Duty Cycle for the Digital Output.
Value Range: 1 - 100 %
Profile Disabled by default. Click Enable to activate this profile setting.
Save Button Click the Save button to save changes to the configuration.
Table 240 – Digital Output (DO) Profile Configuration
8.2.2 Managing Events
Managing Events allow administrator to define the relationships (rules) between event triggers, handlers and responses.
Managing Events functionality is disabled by default, to enable this tool select Event Handling from the Service submenu and
click on the Managing Events tab.
Figure 388 – Enable Managing Events
Item Notes Description
Managing Events Disabled by default. Click Enable to activate the Managing Events functionality.
Table 241 – Enable Managing Events
The Managing Event List supports a maximum of 128 rules.
Figure 389 – Managing Event List
Click the Add button.
