7.1.3.6 Create/Edit Trap Event Receiver
The SNMP allows you to customise your trap event receiver. The router supports up to a maximum of four Trap Event
Receiver sets.
Figure 320 – Trap Event Receiver List
Click the Add button to open the Trap Event Receiver Rule Configuration screen.
Both default SNMP Version of v1 and the user-selected SNMP Version v2c use the following configuration settings:
Figure 321 – Trap Event Receiver Rule Configuration
If you select SNMP Version v3 the following configuration screen containing more settings will be displayed:
Figure 322 – Trap Event Receiver Rule Configuration
Item Notes Description
Server IP Mandatory field.
String format: any IPv4
address.
Specifies the trap Server IP. The NTC-400 Series Router
sends trap to the server IP.
Server Port Mandatory field.
String format: any port
number
Specify the trap Server Port.
You can enter in any port number, but you must ensure
the port number is not already in use.
