No. Description Notes
7 CELL1 AUX Socket Connect one of the 3G/LTE Antennas here.
8 GPS Antenna Socket Connect the included GPS antenna to this socket.
Table 1 – Interfaces (Rear)
1.2.2 LED indicators
LED Icon Status Description
GPS Off GNSS function is disabled.
On Location is fixed.
Flashing Fixing location.
PWR Off Device is powered off or is in standby mode.
On Device is powered on.
Flashing one per second Device is in “Delay off” mode.
Fast flashing Firmware upgrade in process or device is in recovery mode.
2.4G Off 2.4GHz WiFi is disabled.
On 2.4GHz WiFi is enabled.
Fast flashing Data is being transmitted via the 2.4GHz WiFi network.
5G Off 5GHz WiFi is disabled.
On 5GHz WiFi is enabled.
Fast flashing Data is being transmitted via the 5GHz WiFi network.
SIM A Off No SIM inserted or the SIM slot is not being used for a 3G/4G
connection.
On SIM card is inserted and being used for a 3G/4G connection.
SIM B Off No SIM inserted or the SIM slot is not being used for a 3G/4G
connection.
On SIM card is inserted and being used for a 3G/4G connection.
HIGH On 3G/4G signal strength is at a high level.
LOW On 3G/4G signal strength is at a low level.
WAN/LAN1-3 On Ethernet connection established on the corresponding LAN/WAN port.
Flashing Data is being transmitted or received on the port.
Table 2 – LED indicators
