1 Product introduction
1.1 Package contents
1 x NTC-400 Series Router
2 x 2.4GHz/5GHz WiFi antennas
1 x 8-way terminal connector
2 x Mounting brackets
4 x Mounting bracket screws
1 x Quick start guide
1.2 Device overview
1.2.1 Interfaces
Figure 1 – Interfaces (Front)
No. Description Notes
1 USB Type A port Connect a USB storage device.
2 SIM A and SIM B slots Insert SIM cards into the SIM slots to use a cellular network. When two SIM cards are
inserted, you can configure one to operate as primary and the other as a backup (failover).
3 Reset button Used to reset the device to factory default settings. Hold the reset button down for 6
seconds, then release it to reboot the device with the factory default settings.
