3.3.1.10 WDS Only Mode
In WDS Only mode, the device only bridges the connected wired clients to other WDS-enabled WiFi devices that are
associated with it.
Figure 115 – WDS Only Mode
Item Notes Description
Green AP Disabled by default. Check  Enable to activate the Green AP function. Green AP attempts to optimise
wireless throughput and power consumption.
Channel Mandatory field.
Default setting: Auto
Select a radio channel for the VAP. Each channel corresponds to a different radio
band. The permissible channels depend on the Regulatory Domain.
There are two available options when Auto is selected:
By AP Numbers - The channel will be selected according to AP numbers (lower
channels are better).
By Interference - The channel will be selected according to interference. (lower
interference is better).
Authentication Mandatory field.
Default setting: Auto
For security, there are several authentication methods supported. Client stations
should provide the key when associate with this device.
When Open is selected, the check box named 802.1x shows up next to the dropdown
list.
802.1x (Disabled by default.) - When 802.1x is enabled, the client stations will be
authenticated by a RADIUS server.
RADIUS Server IP (The default IP is 0.0.0.0)
RADIUS Server Port (The default value is 1812)
RADIUS Shared Key
When Shared is selected, the pre-shared WEP key should be set for authenticating.
When Auto is selected, the device will select Open or Shared by requesting the client
automatically.
The check box named 802.1x shows up next to the dropdown list.
802.1x (Disabled by default.) - When 802.1x is enabled, the client stations will be
authenticated by RADIUS server.
RADIUS Server IP (The default IP is 0.0.0.0)
To Next Page
