8.1.1.2 Create / Edit 3G/4G Data Usage Profile
Click the Add button to open the 3G/4G Data Usage Profile Configuration screen. You can create up to two data usage
profiles, one profile for each SIM card used in the router.
Figure 356 – 3G/4G Data Usage Profile Configuration
Item Setting Notes Description
SIM Select 3G/4G-1 and SIM A
are the default
selections.
Choose a cellular interface (3G/4G-1 or 3G/4G-2), and a SIM card
(SIM A or SIM B) associated with the selected cellular interface.
Carrier Name Optional Fill in the Carrier Name for the selected SIM card for
identification purposes.
Cycle Period Days by default Select the cycle period type rom the dropdown list: Days, Weekly
or Monthly
Days – For per Days cycle periods, you have to further specify the
number of days in the second box.
Value Range: 1 - 90 days.
Weekly, Monthly – The cycle period is one week or one month.
Start Date N/A Specify the date to start measure network traffic.
Please don’t select the day before now, otherwise, the traffic
statistics will be incorrect.
Data
Limitation
N/A Specify the allowable data limitation for the defined cycle period.
Connection
Restrict
Un-Checked by
default.
Check  Enable to activate the connection restriction function.
During the specified cycle period, if the actual data usage
exceeds the allowable data limitation, the cellular connection will
be forced to disconnect.
Enable Un-Checked by
default.
Check  Enable to activate the data usage profile.
Table 221 – 3G/4G Data Usage Profile Configuration
