4.1.1.1 Create a Time Schedule
When Add button is clicked the Time Schedule Configuration and Time Period Definition sections display.
Figure 194 – Time Schedule configuration
Item Notes Description
Rule Name Enter string: any text, spaces
allowed
Enter a meaningful name.
This Rule Name will be included in the drop down lists
throughout the NTC-400 Series Router that reference
Scheduling Rules.
Rule Policy Default setting: Inactive Inactivate/activate the function during the time periods
defined below.
Table 109 – Time Schedule Configuration
Item Notes Description
ID Reference Integer Use this reference number to apply the time schedule rule
to various applications found throughout the NTC-400
Series Router.
Week Day Drop down list Select Every Day or one week day.
Start Time Time format (hh:mm)
24 hour time.
Start time in the selected weekday(s)
End Time Time format (hh:mm)
24 hour time.
End time in the selected weekday(s)
Save Button Click Save to save the settings.
Undo Button Click Undo to cancel the settings.
Refresh Button Click the Refresh button to refresh the time schedule list.
Table 110 – Time Period Definition
