Item Notes Description
Load Balance
Strategy
Mandatory field.
Default setting: By
Smart Weight
There are three load balance strategies:
By Smart Weight – The system will operate load balance function automatically based
on the embedded Smart Weight algorithm.
By Specific Weight – The system will adjust the ratio of transferred sessions among all
WANs based on the specified weights for each WAN.
By User Policy – The system will route traffic through an available WAN interface
based on user defined rules.
Save Button Click the Save button to save the configuration
Undo Button Click the Undo button to restore what you just configured back to the previous setting.
Table 49 – Load Balance Configuration
When By Specific Weight is selected, user needs to adjust the percentage of WAN loading. System will give a value according
to the bandwidth ratio of each WAN at first time and keep the value after clicking Save button.
Figure 75 – Weight Definition
Item Notes Description
WAN ID NA The Identifier for each available WAN interface.
Weight Mandatory field. Set
with bandwidth ratio of
each WAN by default.
Enter the weight ratio for each WAN interface. Initially, the
bandwidth ratio of each WAN.
Default setting:
Value Range: 1 - 99.
Note – The sum of all weights can’t be greater than
100%.
Save Button
Click the Save button to save the configuration.
Undo Button Click the Undo button to restore what you just configured back
to the previous setting.
Table 50 – Weight Definition
When By User Policy is selected, a User Policy List screen will appear. With properly configured policy rules, the system will
route traffic through an available WAN interface based on user defined rules.
3.1.4.7 User Policy List
Figure 76 – User Policy List
