6.1.1.11 Create/Edit Dynamic VPN Server List
Figure 246 – Dynamic VPN List
Similar to creating an IPSec VPN Tunnel for site/host to site/host scenario, when Edit button is applied a series of
configuration screen will appear. They are Tunnel Configuration, Local & Remote Configuration, Authentication, IKE Phase,
IKE Proposal Definition, IPSec Phase, and IPSec Proposal Definition. You have to configure the tunnel details for the router
as a Dynamic VPN server.
Note – You can configure one Dynamic VPN server for each WAN interface.
Figure 247 – Dynamic VPN Server
Item Notes Description
Tunnel
Disabled by default. Check the
Enable
box to activate the Dynamic
IPSec VPN tunnel.
Tunnel Name
Mandatory field.
String format can be
any text.
Enter a meaningful tunnel name.
Value Range: 1 - 19 characters.
Interface
Mandatory field.
Default setting:
WAN 1
Select the
WAN
interface on which the IPSec tunnel is
to be established.
Tunnel Scenario Mandatory field.
Default setting:
Dynamic
VPN
The IPSec tunnelling scenario is fixed to
Dynamic
VPN
.
Hub and Spoke Mandatory field.
Default setting:
None
Select
None
,
Hub
or
Spoke
Operation
Mode
Mandatory field.
Default setting:
Always
on
The available operation mode is:
Always On
Failover
option is not available for the Dynamic
IPSec scenario.
