NetCommWireless NTC-400 Series User Manual

NTC-400 Series
211 of 361
© NetComm Wireless 2018
Item Notes Description
Encapsulation
Protocol
Mandatory field.
Default setting: ESP
Select the Encapsulation Protocol from the
dropdown box for this IPSec tunnel.
Available encapsulations are ESP and AH.
Table 147 – Dynamic VPN Server
Figure 248 – Local & Remote Configuration
Item Notes Description
Local Subnet Mandatory field. Enter the Local Subnet IP address.
Local Netmask Mandatory field. Enter the Local Subnet Mask.
Table 148 – Local & Remote Configuration
Figure 249 – Authentication
Item Notes Description
Key
Management
Mandatory field.
Pre-shared Key 8
to
32 characters.
Select Key Management from the dropdown box for this IPSec tunnel.
IKE+Pre-shared Key – user needs to set a key (1 - 32 characters).
IKE+X.509 – user needs Certificate to authenticate. IKE+X.509 will be
available only when Certificate has been configured properly.
Refer to Certificate section of this manual and also Object
Definition > Certificate in web-based utility.
Manually – user needs to enter key ID to authenticate.
Manual key configuration will be explained in the following
Manual Key Management section.
Local ID Optional field. Specify the Local ID for this IPSec tunnel to authenticate:
User Name – The u sername may include letters and numbers,
but cann ot be all numbers.
FQDN – Enter the FQDN.
User@FQDN – Enter the User@FQDN.
Key ID – The Key ID can be letters and/or numbers.
Remote ID Optional field. Specify the Remote ID for this IPSec tunnel to authenticate.
