6.2.2.3 Create/Edit Packet Filter Rules
When
Enable
is selected, the buttons on the Packet Filter List section become active.
Figure 285 – URL Blocking Rule List
Click on the Add button to create a new rule in the list. You can add up to twenty (20) URL Blocking rules.
Figure 286 – URL Blocking Rule Configuration
Item Notes Description
Rule Name
Mandatory field.
String format.
Enter a meaningful name of up to 30 characters for the URL blocking rule.
Source IP
Mandatory field.
Default setting: Any
This field is to specify the
Source IP address
.
Select Any to filter packets coming from any IP addresses.
Select Specific IP Address to filter packets coming from an IP address
entered in this field.
Select IP Range to filter packets coming from a specified range of IP
address entered in this field.
Select IP Address-based Group
from the drop down list to filter packets
coming from the selected group.
Note – Groups must be pre-defined before this selection
become available in the drop down list.
Refer to Object Definition > Grouping > Host grouping.
Alternatively, click the Add Rule button that displays when
this drop down list is empty to create a new group.
Source MAC
Mandatory field.
Default selection: Any
This field specifies the source MAC address or addresses.
Select Any to filter packets coming from any MAC address.
Select Specific MAC Address to filter packets coming from a MAC
address entered in this field.
