Item Notes Description
Ping Test Host IP Specify an IP / FQDN that the system can ‘ping’ to test whether the
connection is functioning.
Interface Select Auto, WAN-1 or LAN from the drop-down list.
Auto is the default setting.
Ping button Click the Ping button and the Ping Test Results window will appear
beneath the tools section.
Tracert Test Host IP Tracert (Trace route) command is a network diagnostic tool for
displaying the route (path) and measuring transit delays of packets
across an IP network. Trace route proceeds until all (three) sent packets
are lost for more than twice, then the connection is lost and the route
cannot be evaluated.
In the Host IP text box specify an IP / FQDN address, the test interface
(Auto) and the protocol (UDP, the default, or ICMP).
Interface Select Auto, WAN-1 or LAN from the drop-down list.
Auto is the default setting.
Protocol Select UDP or ICMP from the drop-down list.
UDP is the default setting.
Tracert button When the Tracert button is clicked the system will try to trace the
specified host to test whether it is ‘alive’.
The Tracert Test Results window will appear beneath the tools section.
Wake on
LAN
Optional
setting
Wake on LAN (WOL) is an Ethernet networking standard that allows a
computer to be turned on or awakened by a network message.
Specify the MAC address of the computer, in your LAN network, to be
remotely turned on when the Wake up button is clicked.
Save Button Click the Save button to save the configuration.
Table 220 – Diagnostic Tools
