When Add button is applied, an APN Profile Configuration screen will appear.
Figure 65 – SIM-A / SIM-B APN Profile Configuration
Item Notes Description
Profile Name By default Profile-x is listed.
String format: any text
Enter the profile name you want to describe for this profile.
MCC String format: integer Enter the MCC (Mobile Country Code) you want to use for this profile.
Note – the MCC is related to the MNC and can’t be blank or set to an
invalid value if MNC is filled-in.
MNC String format: integer Enter the MNC (Mobile Network Code) you want to use for this profile.
Note – the MNC is related to the MCC and can’t be blank or set to an
invalid value if MCC is filled-in.
APN String format: any text Enter the APN you want to use to establish the connection.
Account String format: any text Enter the Account you want to use for the authentication.
Value Range: 0 - 53 characters.
Password String format: any text Enter the Password you want to use for the authentication.
Authentication
Mandatory field.
Default setting: Auto
Select the Authentication method for the 3G/4G connection: Auto, PAP, CHAP, or
None
Priority Mandatory field.
String format: integer
Enter a value for the connection order. Valid values are 1 to 16. The router will
attempt to connect to profiles with a lower value.
Value Range: 1 - 16.
Profile Enabled by default. Check the box to enable this profile.
Uncheck the box to disable this profile in the dial-up action.
Save Button Click the Save button to save the configuration.
Undo Button Click the Undo button to restore what you just configured back to the previous
setting.
Back Button When the Back button is clicked, the screen will return to the previous page.
Table 45 – SIM-A / SIM-B APN Profile Configuration
