100 ProSYS Installation and Programming Manual
Utility Output: Zone
Quick Keys Parameter
Activates the Utility Output when the selected zone is armed by the system.
33
33
44
Disarm Follow
Activates the Utility Output when the selected zones are disarmed.
4 Press / . The following display appears:
5 Enter the zone numbers in the group and press
/ after each one. For
each Utility Output, you can define a group of up to five zones.
NOTE:
If you choose a zone number that is not in the system, a broken line is displayed (---).
6 Press
/ and proceed to Pattern of Operation, page 100, to set the
pattern and duration of operation.
33
44
Utility Output: User Code
The Code menu parameters enable you to program the activation of the selected Utility
Output when the user chooses the User Functions menu (selects ACTIVITIES/UTIL
OUTPUT, enters an authorized User Code and presses press
/ ). The Installer
designates the User Code(s) for triggering the selected UO.
Refer to the ProSYS User's Manual for additional details about triggering Utility Output(s) via
User Codes.
NOTE:
The Utility Output will be activated by entering a User Code only if the Quick UO parameter under System
Control is defined as Disabled. When the Quick UO is defined as Enabled, no User Code is required.
 To access the Code menu:
Access the Utility Output menu, as described on page 93.
1 From the Utility Output menu, press [4]. The following display appears:
2 Press
/
to access the Code menu options. The following display
appears:
3 Use the
/ or / keys to select from any of the 99 available
User Codes.
4 Use the
/ key to toggle between [Y] YES or [N] NO for each user
chosen to trip the designated Utility Output.
5 Press / and proceed to the following Pattern of Operation submenu to
set the pattern and duration of operation:
