184 ProSYS Installation and Programming Manual
Access Control: Door Define
Quick Keys Parameter Default Range
4. Press / .
99 11 22 33
Door Alarm Delay
10 seconds 1-99 seconds
Determines the amount of time that the door can remain open before an alarm
is activated (triggered on relay 3). This option also determines the amount of
time that passes until an alarm is activated when the door is forced open.
1. Press [2] and
/ to enter the door time settings.
2. Press [3] and
/ .
3. Enter the number of seconds (between 1-99) to define the door alarm relay
time.
4. Press
/ .
99 11 33 Door Fire Settings
Open Open/Closed
Determines the status of the door during a fire alarm as either open or closed.
Once a fire alarm is triggered by the ProSYS, the system sends a fire alarm
notification to the Access Control module, which sets the door relay to the
required position during the fire alarm.
1. Press [3] and
/ .
2. Toggle the
/ key to select the appropriate option, as
follows:
O YES: Keeps the door open during a fire alarm.
O NO: Keeps the door closed during a fire alarm.
3. Press
/ .
99 11 44 Door Input Settings
Defines the status of the door relay input during operation.
1. Press [4] and
/ .
2. Select the required door relay input:
O Door Contact
O Request to Exit (RTE) Button
99 11 44 11
Door Contact
NO (normally open) NO/NC
This door contact starts a timer in the reader interface that notifies the system
w
hen a door is open. Press [4] and / to enter the door input
settings.
1. Press [1] and
/ .
2. Toggle the
/ key to select the appropriate door contact
termination, as follows:
O NO: Sets the door contact to normally open.
O NC: Sets the door contact to normally closed.
3. Press
/ .
