ProSYS Installation and Programming Manual 181
GSM Parameters
Quick Keys Parameter Default
88 33 11 66 55
SMTP E-mail prefix
The GSM e-mail address prefix. Up to 16 characters can be used to define the
e-mail prefix. For example, in the GSM@riscogroup.co.uk e-mail address, the
prefix name is “GSM”).
88 33 11 66 66
SMTP E-mail domain
The GSM e-mail address domain name. Up to 33 characters can be used to
define the e-mail domain. For example, in the e-mail address
GSM@riscogroup.co.uk, the domain name is riscogroup.co.uk.
Note:
Do not enter the @ sign
88
33
11
77
Caller ID
The Caller ID function enables the GSM module to restrict SMS remote control
operations to predefined phone numbers (Follow Me numbers).
The Caller ID function is performed according to the following:
The module checks the last digits (defined number of digits) of the telephone
number from which the SMS was sent from, and compares them, to the last
digits of the Follow Me telephone numbers defined in the ProSYS. If the digits
coincide, the number is recognized as one of the Follow Me numbers and the
operation will be executed.
Set the number of digits to be checked by the module.
88
33
11
88
RSSI Level
The GSM Signal Level (RSSI) depends on the location in which the
GSM/GPRS BUS Module is installed. This option allows you to set the lowest
acceptable GSM Signal level.
Set the minimum acceptable RSSI level using the numeric keys
(0= No network connection, 5=High).
Please be aware of the fact that this feature is used for trouble shooting
purpose only.
88
33
22
GSM Control
This sub menu enables to program parameters allowing proper operation of the GSM module
Devices: GSM
Quick Keys Parameter Default
88
33
22
11
Disable Incoming Call
No
This parameter is used to disable all incoming calls trying to come in via the
GSM voice channel.
Notes:
1. Only SMS or Upload/Download incoming calls are allowed.
2. This parameter is relevant only for GSM/GPRS full version module.
