Uses normally-closed (NC) and/or normally-open (NO) contacts in a zone
terminated by a supplied 4.7 KΩ End-of-Line Resistor (provided).
22 55 ZZZZ +
/
0303
DEOL
Uses normally-closed (NC) contacts in a zone using 4.7 KΩ +6.8 KΩ End-
of-Line Resistors to distinguish between alarms and tamper conditions. See
Figure 2-4: Zone Connection Diagram in Chapter 2, Mounting and Wiring the
Main Panel.
22 55 ZZZZ
+
/
0404
N/O
Uses normally-open contacts and no terminating End-of-Line Resistor.
22 55 ZZZZ +
/
0505
BUS Zone
Use this option to define termination for any BUS zone. After pressing
/ you need to assign the current programmed zone with a
BUS zone number (ID field). The type field will be updated automatically
w
hen selecting the zone.
22 55 ZZZZ +
/
0606
TEOL
Uses normally-closed (NC) contacts in a zone to distinguish between
alarms, tamper conditions and fault/AM conditions using 4.7 KΩ +6.8 KΩ +
12 KΩ End-of-Line Resistors.
22 55 ZZZZ
+
/
0707
BUS Zone Input N/C
Use this option to define N/C termination (see above description) for the
relay zone input that exists on a BUS zone detector.
22 55 ZZZZ +
/
0808
BUS Zone Input EOL
Use this option to define EOL termination (see above description) for the
relay zone input that exists on a BUS zone detector.
22 55 ZZZZ
+
/
0909
BUS Zone Input DEOL
Use this option to define DEOL termination (see above description) for the
relay zone input that exists on a BUS zone detector.
22 55 ZZZZ +
/
1010
BUS Zone Input N/O
Use this option to define N/O termination (see above description) for the
relay zone input that exists on a BUS zone detector.
22 55 ZZZZ +
/
1111
BUS Zone Input TEOL
