Risco ProSYS series - Wiring the Auxiliary Devices

22 ProSYS Installation and Programming Manual
The following table
indicates the EOL limit values when the ProSYS panel detects a status
difference. Please respect the EOL standard values given in the installation manual to prevent
unexpected alarms.
Zone Type
Impedance (KΩ)
Zone Mode
NO
47.1<R Ready
R<47.1 Trip
NC
6.97<R Trip
R<6.97 Ready
EOL
6.97<R Trip
3.07<R<6.97 Ready
R<3.07 Trip
DEOL
13.95<R Tamper
6.97<R<13.95 Trip
3.07<R<6.97 Ready
TEOL
47.1<R Tamper
19.92<R<47.1 Anti Mask
13.95<R<19.92 Fault
6.97<R<13.95 Trip
3.07<R<6.97 Ready
R<3.07 Tamper
TEOL uses normally-closed (NC) contacts in a zone to distinguish between alarm, tamper
condition and fault/AM condition using 4.7K and fault/AM condition using 4.7KΩ + 6.8KΩ +
12KΩ End-of-Line resistors.
Wiring the Auxiliary Devices
 To wire auxiliary devices:
Use the Auxiliary Power AUX (+) COM (-) terminals to power PIRs, glass-break detectors
(4-wire types), smoke detectors, audio switches, photoelectric systems and/or any device
that requires a 12V DC power supply.
