ProSYS Installation and Programming Manual 135
Dialer: More
Quick Keys Parameter
55
00
22
00
More
[1] U/D IP Mask: The IP address from which a connection to the ACM can be
established via the U/D software.
[2] ACM Net Name: A text name used to identify the ACM module over the
network.
[3] DNS#1 IP: Provision for optional functionality
[4] DNS#2 IP: Provision for optional functionality
[5] NTP IP: Network Time Protocol server IP address.
[6] NTP Port: Network Time Protocol server IP port.
[7] NTP UPD Time: Network Time update interval specified in days.
55
00
33
ACM Control
See ACM Installer Manual for more information.
55
00
33
11
ACM Configuration
Defines the ACM parameters configuration.
[1] Client ATN (default N): Provision for optional functionality
[2] DHCP IP (default N): Defines whether the IP address, which the
ACM refers to, is static or dynamic.
55
00
33
22
ACM UD Configuration
[2] Enabled
Defines the authorization type when using the U/D software application over
the Ethernet network;
[1] Disabled
[2] Enabled
55
00
33
33
ACM AUX 1 Configuration
MODBUS protocol support
[1] Disabled
[2] Enabled
55
00
33
44
ACM AUX 2 Configuration
Provision for optional functionality
[1] Disabled
[2] Enabled
55
00
33
55
ACM AUX 3 Configuration
Provision for optional functionality
[1] Disabled
[2] Enabled
55
00
44
IP MS Polling
This parameter checks connectivity between RISCO Group's IP/GSM Receiver
software and the ProSYS panel by sending polling signals from the ProSYS
ACM via the IP channel. Ensure that the IP channel has been configured
properly in the IP/GSM Receiver software.
The information regarding which MS is to be used to perform the polling is
To Next Page
