64 ProSYS Installation and Programming Manual
IMPORTANT:
When using the One by One method, the listing of each zone's parameters is sequential.
Once Zone 1's parameters have been programmed, they are followed by Zone 2's, then
Zone 3's, and so forth.
To program one or more of the system's zones using the One by One method, changes
made to any (or all) of the Zone parameters will NOT be recorded without going through
the One by One list, ending with the Zone Labels parameter of the last zone you want to
program.
After making changes to the Zone Labels parameter, press
/
. This produces a
one-second tone and assures that change(s) you make to the zone programming are
recorded when you exit the One by One programming mode.
As mentioned before, you can select a single parameter and program (or review) it for each
of the system's zones, as follows:
[2] Partitions/Groups, below
[3] Zone Type, page 65
[4] Zone Sound, page 70
[5] Termination, page 71
[6] Loop Response, page 73
[8] Zone Labels page 75
22
22
Zones: Partitions
Default: All zones are assigned to Partition X
Range: Partitions 1 to 8
The Partitions menu contains parameters that enable you to program the partition assignment
for each zone.
 To access the Partitions menu:
1 Access the Zones menu, as described on page 62.
2 From the Zones menu, press [2] to access the Partitions menu options. The following
display appears:
3 Specify a two-digit zone number and press
/ . The following display
appears:
NOTES:
The XX in the Z=XX designation refers the zone number.
In a multi-partitioned system, a zone can be assigned to more than one partition.
A system without partitions is regarded as having a single partition (meaning Partition 1).
4 Use keys [1] to [8] to toggle the partition status between [Y] YES or [N] NO.
5 Press
/ . The following display appears:
