102 ProSYS Installation and Programming Manual
Utility Output: Pattern of Operation
Quick Keys Parameter Default Range
NOTE:
You can create and/or edit a 10-character label description for each Utility Output. Refer to Entering a
New Label Using the LCD Keypad, page 58, for additional details.
Activation/Deactivation
When the Utility Output is following more than one Partition or Zone, the Installer can choose
the logic of the Utility Output activation or deactivation, as follows:
If the Pattern of Operation is defined as Latch N/O or Latch N/C, the Installer can choose the
activation and deactivation logic of the UO to follow either after all the Partitions/Zones
or after any of the Partitions/Zones.
If the Pattern of Operation is defined as Pulse N/O or Pulse N/C, the Installer can choose
only the activation logic of the Utility Output to follow either after all the Partitions/Zones
or after any of the Partitions/Zones. The deactivation operation follows the defined time
period.
